How To Bring Stateflow Under Control with Modeling Guidelines
Stateflow is a powerful tool in model-based development, particularly in industries like automotive, where precise control of state machines and complex logic is essential. However, effectively using Stateflow requires overcoming recurring challenges, such as syntax issues and performance considerations.
In this article, we explore key insights from a survey conducted by MES and provide actionable tips to optimize your Stateflow models for improved performance, reliability, and maintainability.
How Do Industry Professionals Use Stateflow: Survey
Level of Stateflow Adoption in Model-Based Development
As part of our ongoing efforts to understand industry practices, we conducted a Stateflow-focused survey in 2022 in collaboration with 30 experts from companies including Go to Mercedes-Benz Group AG, Go to Bosch Group, Go to Continental AG, and others.
We started by asking whether they, as professionals working with model-based development, use Stateflow. As shown in the bar chart below, most users incorporate Stateflow in 20% to 50% of their models.
Preferred Action Language for Stateflow
The second question we asked was which action language they used. The pie chart below highlights that most users prefer MATLAB over C language for action scripting, reflecting its simplicity and integration with the Simulink ecosystem.
Common Obstacles in Using Stateflow
Third, we asked participants about the challenges they face when using Stateflow. The most common obstacle was a lack of knowledge, with a notable number of users reporting no difficulties at all. Missing features were the least cited concern, suggesting that training and documentation improvements could help users overcome their hurdles.
Use of Stateflow for Arithmetic Calculations
The fourth inquiry was regarding the use of Stateflow for arithmetic calculations. A majority of 56% responded affirmatively. This highlights the tool's versatility in handling complex calculations often needed in automotive systems.
Most Commonly Used Stateflow Elements/Patterns
Finally, we inquired about the most frequently used Stateflow elements and patterns. The results indicated a relatively uniform distribution, with Statecharts and Condition Actions showing a slightly higher usage rate, while Boxes exhibited the lowest adoption. This suggests a preference among participants for structured, condition-based modeling, particularly for implementing decision logic within their systems.
Key Takeaways From the Survey
Our survey reaffirms that Stateflow is part of the toolset used by professionals in model-based development. However, the responses also reveal several challenges users face when using it.
Based on this feedback, the MES team identified common pain points and areas for improvement. In this article, we will explore these challenges in detail and provide best practices to enhance the efficiency and reliability of Stateflow modeling.
What Challenges Make Model-Based Development With Stateflow Difficult?
Model-based development with Stateflow offers powerful capabilities, but it also comes with challenges that can impact maintainability and efficiency. Key difficulties include:
- Increasing complexity: As state transitions grow, managing them becomes more difficult.
- Scalability issues: State machines can quickly expand, making models harder to read and maintain.
- Syntax constraints: Strict syntax rules are necessary to ensure consistency and prevent errors.
- Careful design required: A structured approach and disciplined use of Stateflow are essential to avoid unexpected behavior and improve model clarity.
10 Strategies to Master Stateflow
1. Ensure Proper Syntax for Transition Labels
Proper transition label syntax in Stateflow improves readability, maintainability, and predictability while ensuring accurate code generation in tools like TargetLink. A structured approach helps create clear, reliable, and easy-to-maintain models.
First, let's break down and explain the meaning of each part of a transition label:
- Event: Specifies an event that causes the transition to be taken
- Condition: Specifies a Boolean expression that, when true, validates a transition to be taken
- Condition action: Executes as soon as the condition is evaluated as true
- Transition action: Executes after the transition destination has been determined to be valid provided the condition
A possible syntax is the following: The format is: trigger [condition] {condition_action} /transition_action.
Keep in mind that you do not have to use all of them. Avoid events and use conditions, as they are standard. Additionally, decide between condition actions and transition actions.
2. Adhere to the Safe Modeling Language Subset
Based on modeling guidelines: mes_slsf_3110 | misra_slsf_047_ab | misra_slsf_046_a
History Junctions should be avoided as they can:
- Lead to misinterpretation of the model.
- Complicate the validation process.
- Hide functionality, making the system harder to understand and maintain.
The image below showcases a history junction, marked by the H symbol. This could lead to the mistakes mentioned previously.
Events should also be avoided because they can:
- Lead to recursion issues.
- Cause unintended functionality.
- Hide functionality, making it difficult to comprehend and maintain the model.
Which Stateflow action guidelines are safe to use?
The recommendation is to choose one type of action, either Condition Actions, Transition Actions or State Actions, and use it consistently throughout the model.
3. Use Condition and Transition Actions Correctly
Based on modeling guidelines: misra_slsf_045_e | misra_slsf_045_f | misra_slsf_045_g
Avoid Writing Variables in Condition and Transition Actions: Modifying variables within condition or transition actions can lead to unexpected behavior and complicate debugging.
Prevent Reading Transition-Written Variables in Subsequent Transitions: A variable modified in a transition-action should not be read in a subsequent transition, as it can lead to inconsistencies in execution order.
Single Transition-Action Writing: To maintain predictable behavior, a variable should only be modified by a single transition-action when moving between states.
4. Avoid Crossing Transitions in Stateflow
Based on modeling guidelines: mes_slsf_3109
To maintain clarity and prevent graphical overlaps, avoid transitions that cross state boundaries in Stateflow charts. Crossing transitions can make the chart difficult to read, increasing the risk of misinterpretation and errors.
In addition, a cluttered layout complicates debugging and maintenance, making it harder to track the flow of execution. By organizing transitions logically and keeping paths clear, you can improve model readability, maintainability, and overall reliability.
In the graphs below, transitions crossing parallel state boundaries are evident. It's crucial to avoid such crossings, as they can lead to confusion and potential modeling errors.
5. Do Not Use Equality Operators With Floating-Point Operands
Based on modeling guidelines: jc_0481 | mes_sltl_002
You should avoid the floating-point comparisons with the following equality comparison operators:
- ==
- !=
- ~=
- <>
Floating-point numbers have small rounding errors due to their binary representation, making exact comparisons unreliable. This can lead to incorrect results because two mathematically equal values may have tiny differences in memory. This is why using hard equality (strict bit-by-bit comparison) for floating points is not recommended.
6. Avoid Backtracking in Stateflow
Based on modeling guidelines: mes_sf_002 | misra_slsf_043_h
Stateflow does not support backtracking. This means that all executed actions remain in effect, regardless of whether the transition path reaches the intended final state. If a transition path fails to reach a valid end state, it can lead to unexpected behavior.
To prevent such issues, ensure that each transition path includes an unconditional default path. Additionally, either use condition actions only in the final segment of the transition or opt for transition actions instead.
(As discussed in Section 3, there are valid reasons to choose transition actions.)
Example of a backtracking issue:
7. Follow Best Practices for Setting Execution Orders
Based on modeling guidelines: mes_is_0002
Stateflow defines the execution order clockwise, especially for parallel states. Even slight changes to the graphical arrangement or the addition of a new element can lead to changed execution orders.
The following graph illustrates how the execution order of transitions in a Stateflow chart changes when a new event (Event1) is introduced, highlighting the importance of manually specifying execution orders.
8. Avoid Global Stateflow Functions
Based on modeling guidelines: mes_slsf_3106
Defining Stateflow functions locally within their respective charts is a recommended practice to maintain modularity and prevent unintended interactions.
Using the "Export Chart Level Functions (Make Global)" feature allows graphical functions to be accessed globally in any chart of the model. However, these functions cannot be easily traced (only by searching for the function name) and result in opaque behavior.
Additionally, enabling 'Allow exported functions to be called by Simulink' (available since R2014b) introduces complexities in function management and data flow, so it should not be selected.
9. Skip Recursive Loops
Based on modeling guidelines: jc_0804
Ensuring that graphical functions in Stateflow are neither defined recursively nor call other graphical functions is crucial to prevent unintended behavior and maintain model integrity. Recursive calls can lead to infinite loops, stack overflows, and increased complexity in debugging and maintenance.
The diagram below illustrates a recursive loop problem in Stateflow graphical functions. When func1(x) is executed, it calls func2(x), which in turn calls func1(x), creating an infinite recursion. To prevent this issue, it is recommended to avoid direct or indirect recursive function calls in Stateflow graphical functions.
10. Explicitly Define Input Variables for Seamless Integration
When working with TargetLink, Simulink, and Stateflow, it is essential to explicitly define input variables to maintain a consistent and well-structured interface. dSPACE’s TargetLink Property Manager (as shown in the image below) helps manage these variable definitions, ensuring consistency across the model and final implementation.
Conclusion: Managing Complexity in Stateflow with Modeling Guidelines
Stateflow provides powerful modeling capabilities, but it also introduces risks when not used carefully.
To manage complexity, follow these best practices:
- Keep it simple! Avoid unnecessary complexity in transitions and state logic.
- Perform arithmetic operations in Simulink; otherwise, you risk the chart blowing up and becoming uncontrollable.
- Follow established guidelines to prevent unexpected behavior and error-prone patterns.
- Ensure a clear and structured layout for better readability and maintainability.
- Use tools such as Go to MXAM Product Page to automate modeling guidelines compliance.
By adhering to these best practices, you can create robust, efficient, and maintainable Stateflow models that integrate seamlessly with Simulink and TargetLink.
If you would like to access our library of articles, webinars, research projects, and more on model-based development, check out our Go to Knowledge Library. Stay updated, strengthen your expertise, and create simply better models!
